Technology parameter
Technology parameter | 55gallon/200kg(pressure plate) | 5gallon/20kg(pressure plate) |
Standard operation voltage | 380V/50HZ | 380V/50HZ |
Machine working pressure | 70bar | 70bar |
Total power | ≥28000W | ≥7000W |
Intelligent temperature control system | DTC溫控模塊或麥格米特MT | DTC溫控模塊或麥格米特MT |
Temperature sensor | 2芯鉑金熱電阻或ni120 | 2芯鉑金熱電阻或ni120 |
Operation temperature | 雙層特富龍?zhí)幚恚ㄗ罡吣蜏?30℃) | 雙層特富龍?zhí)幚恚ㄗ罡吣蜏?80℃) |
Drum diameter | 55加侖桶經 | 5加侖桶經 |
Standard platen power | ≥27000W | ≥6000W |
Motor qty | 1 | 1 |
Adjustable speed motor | 0-57轉可調 | 0-57轉可調 |
Motor control | stepless speed | stepless speed |
Gear pump | 1臺 | 1臺 |
Displacement per revolution(gear pump) | ≥30.0cc/r | ≥5.0cc/r |
Gear pump rste | ≥70L/Hour | ≥15L/Hour |
Max.Operation temperature | MAX230℃ | MAX230℃ |
Standard output volume | 1 route or more | 1 route or more |
Pumping capacity per hour | manual/external cotrol | manual control(adjustable) |
Pumping control | manual/external cotrol | auto control external signal |
Intelligent insulation function | yes | yes |
Intelligent sleep system | yes | yes |
Empty drum alarm | yes | yes |
Motor overheat protection | yes | yes |
Plate overheat protection | yes | yes |
One-touch thermal insulation | yes | yes |
Sound and light alarm | yes | yes |
Lower temperature star protection | yes | yes |
Over-current protection | yes | yes |
Leakage shutdown protection | yes | yse |
Extemal signal interface | (aviation connector) | (aviation connector) |
Machine size(about) | 1520*660*1760mm | 1060*580*1560mm |
Total weight(about) | ≥360Kg | ≥260Kg |
Application
Wood coating fitting, textiles lamination, PET transparent boxes, auto inner decoration pieces, bookbinding, household appliance assembly etc.
