TCB-Ⅲ(300/450)EVA hot glue profile wrapping machine

TCB-Ⅲ(300/450)EVA hot glue profile wrapping machine


Technology parameter


Max film covering width

300mm

Max process thickness90mm
Min process length600mm
Speed of material delvery0-30m/min
Motivity power1.5kw
Sticking glue power0.4kw
Heating power6kw
Max diameter of roll cover material

400mm

Fiexible maximum width of cover film400/600/900/1200mm
Machine weight≈2000kg
Structure sizeL4000/5000/6000×W600×H2000mm


Product principle


Works by using the pressure roller of different angles to coat on the workpiece to suppres,in the process,the process pressure rate and pressure can be adjusted according to different coating materials.


A full set of manufacturing processes can be a full automatic assembly line,the normal working can be done without human intervention,it just need to feed material from adhesive coating and film wrapping until the product is finishde,which reduce labor costs and ensure the passing rate of processde products and processing efficiency.


Suitable for building materials,furmture,tabletops,doors,windows,trim or related manufacturers use.
